LAY FLAT TUBING
MEDICAL
LAY FLAT APPLICATIONS
Applications for lay-flat tubing are extensive. In the medical realm, this process can be utilized to construct sheaths to be used as barriers for colonoscopes, endoscopes, speculums, probes, and many other devices requiring protection from moisture, blood, or bacteria. These sleeves can provide a cost advantage over current practice of extensive cleaning or reprocessing.
LAY FLAT
EXTRUSION PROCESS
Blown film extrusion is a process that uses a circular die and create a “bubble” with heat and air. Polyzen does this on a small diameter die. Capabilities include but are not limited to, producing thin-wall tubing with a thickness ranging from 0.0005″ – 0.010″ with a tolerance of +/- 10% of thickness. The small-diameter lay-flat tubing can be extruded at a width ranging from 0.3″ – 2.5″ (lay-flat width). All extrusions are done within a class-10,000 clean room environment.
MEDICAL
LAY FLAT TUBING MATERIALS
Polyzen’s custom tube manufacturing capabilities allow for the use of many standard and custom polymer formulations. Examples include thermoplastic polyurethanes (TPUs), thermoplastic elastomers (TPEs), polyamides (nylons, Pebax*), ethylene vinyl acetates (EVAs), polyvinylidene fluoride (PVDF), polypropylene, and polyethylene. Our in-house compounding capabilities allow us to enhance properties of these polymers with radiopaque fillers, custom colors, stabilizers, and more.
